Delta  Inclined Platform Lift

  • Provides access over a single flight of stairs in residential or commercial settings
  • Carries a passenger in a wheelchair or seated passenger; 550 lb capacity
  • Platform folds up to keep stairs unobstructed; 4 sizes available, including ADA-compliant
  • Battery powered with motor onboard the unit; no machine room needed, and can be operated during a power outage
  • For indoor and outdoor use (moderate climates only)
  • For stairs with multiple levels, curves or intermediate landings, see the Omega IPL

The nuts and bolts

Features

Affordable accessibility option: Provides access without significant renovations.
Space-saving design: Sleekly finished traveling rails and foldaway design.
Machine roomless: The drive system is housed with the lift, so no additional machine room is needed.
Battery powered/charging stations: Battery-operated unit ensures the lift operates through a power failure. Charging stations at the top and bottom ensure the lift is always ready to go.
Other standard features: Constant pressure buttons to move the lift up and down, motor housed on board the lift, modular rail system, manual folding platform, pendant control, keyed call stations, keyed operation.
Standard finish options: Light gray (RAL 7035).
ADA-compliant platform: Optional ADA-compliant platform, ideal for public accessibility requirements.
Safety features: Obstruction sensor system on the platform, non-skid platform with side safety flaps, overspeed governor, manual lowering device, keyed access for call stations and emergency stop button.
Warranty: 36 months parts. Please see complete details here.

Options

Optional configurations: Straight through or side exit (90 degrees) ramp
Platform sizes:
W26.5" x L36" (673 mm x 914 mm)
W30.5" x L49.25" (775 mm x 1250 mm)
W28.35" x L35.43" (720 mm x 900 mm)
W28.5" x L44" (724 mm x 1118 mm)
Other options: Motorized folding/unfolding of platform and safety arms, fold-down seat with 330 lb (150 kg) capacity, and stainless steel rail (required for outdoor applications)
Commercial package: Includes power folding arms and platform, additional battery pack, audio visual alert, folding seat, ADA-compliant platform

Specifications

Applications: Commercial, residential, indoor, outdoor*
Stair types: Straight, single flight with constant gradient
Capacity: 550 lb (250 kg)
Optional capacity: 660 lb (300 kg) USA only
Nominal speed: 15 feet/minute (0.075 metres/second) to 20 feet/minute (0.1 metres/second)**
Minimum travel: 8" (20 cm)
Maximum travel: 80' (24 m)
Motor: 0.66 hp (0.5 kW)
Gradient: Constant, 20º to 45º
Power supply: 24 volts DC (battery system), 120V AC for charger
* For outdoor applications, consult your local Savaria dealer as not all climates may be suitable for outdoor installations
** Note that the speed may vary depending on the angle of the stairs

Documents

    Gallery of installations

    Loading Gallery
    Delta IPL 1Thumbnail for Delta IPL 1
    Delta straight

    Stainless steel lift in a modern foyer

    Delta IPL 2Thumbnail for Delta IPL 2
    Delta straight

    Standard gray color lift at the lower level

    Delta IPL 3Thumbnail for Delta IPL 3
    Delta straight

    Upper level view of a lift in a pedestrian walkway

    Delta IPL 4Thumbnail for Delta IPL 4
    Delta straight

    Folded-up lift in a shopping concourse

    Delta IPL 5Thumbnail for Delta IPL 5
    Delta straight

    Wheelchair user exiting a lift at the lower level

    Delta IPL 6Thumbnail for Delta IPL 6
    Delta straight

    Stainless steel lift in a fold-up position in a foyer

    Delta IPL 7Thumbnail for Delta IPL 7
    Delta straight

    Full stainless steel lift ready for use

    Delta IPL 8Thumbnail for Delta IPL 8
    Delta straight

    Stainless steel lift showing folding seat option

    Delta IPL 9Thumbnail for Delta IPL 9
    Delta straight

    Wheelchair lift at the lower level of a residence

    Delta IPL 10Thumbnail for Delta IPL 10
    Delta straight

    Wheelchair lift over a short set of stairs

    Delta IPL 11Thumbnail for Delta IPL 11
    Delta straight

    View from the top of a lift in at a retail store
