Vertical Material Handling FAQ

Dumbwaiters are designed for smaller loads (maximum capacity under ASME 17.1 is 750 lb or 340 kg) in compact spaces such as retail and restaurant applications, material lifts handle larger and heavier items (maximum capacity under ASME 17.1 is 2500 lb  or 1134 kg), and VRCs are used primarily in industrial or restricted-access environments with higher capacity need and are governed by ASME B20.1. VRCs cannot be used in an area accessible to the general public.

These systems should be considered early in the design phase, as shaftway size, pit depth, overhead clearance, and drive placement can affect structural layout, fire ratings, and overall space planning.

The decision depends on what is being moved, how it will be loaded, and where it is traveling. Smaller hand-loaded items like food and beverage, retail stock and medical supplies typically suit dumbwaiters, while heavier carts, pallets, or industrial loads may require a material lift or VRC.

Dumbwaiters and material lifts can be used in commercial buildings with proper fire-rated enclosures, but VRCs must be located in restricted-access areas and cannot be exposed to the general public.

Dumbwaiters and material lifts fall under ASME A17.1 and CSA B-44 while VRCs are governed by ASME B20.1. Code selection affects enclosure requirements, access control, and how the system can be integrated into the building.

They typically require significantly less space than a freight elevator, however,  exact requirements depend on platform size, loading style, drive type, and travel height. These systems come in a wide variety of car sizes and configurations to suit the load, application and building footprint.

These systems reduce reliance on passenger elevators for moving goods, speed up service and logistics, and lower the risk of staff injuries from manual handling.

Vertical material handling systems are typically 40–60% less expensive to install than freight elevators, with a two-stop dumbwaiter starting at approximately $50,000 USD installed.

They allow food prep, storage, and stock handling to be relocated to lower-cost or below-grade areas, freeing high-value floor space and potentially saving $30,000–$500,000+ annually in lease costs.

They are commonly used to transport food, beverages, laundry, medical carts, pharmaceuticals, retail stock, chemicals, hazardous materials, and sensitive or secure items.

Yes. Building codes prohibit transporting living human beings in dumbwaiters, material lifts, or VRCs.

Counter-loading is ideal for hand-loaded goods such as trays or small items, while floor-loading is preferred for carts, dollies, and larger or heavier wheeled loads.

Winding drum drives are cost-effective and suitable for low- to mid-rise applications, while geared traction drives are better for higher speeds, longer travel distances, or heavier loads.

For buildings up to three or four floors, typical speeds are around 40 feet per minute, keeping travel times under 30–40 seconds.

Most systems operate reliably for more than 25 years before modernization is typically required.

Yes. Many older systems can be upgraded with new controls, motors, and safety devices, extending service life at a fraction of the cost of replacement.
