Eclipse  Home Elevator

  • Our best-selling home elevator; unique modular design with machine roomless option
  • Durable geared chain drive for a reliable, stable ride
  • Services up to 6 stops over a maximum travel distance of 50' (up to 60' in some regions)
  • Capacity up to 950 lb; Eclipse HD version available for higher capacity (depends on local codes)
  • Openings can be configured for same-side, straight-through or 90º entry and exit, depending on the layout of your home
  • Customize cab interior, fixtures and doors here

The nuts and bolts

Features

Machine roomless: Unique design requires only a small space in a closet for components, so a machine room is not needed and less installation time is usually required. In some regions, controller can be placed inside shaft (code permitting).
Compact chain drive system: Requires only 8' ceilings. No ceiling shaftway construction is required.
Hide-away gate: Innovative gate system tucks away for maximum entryway and interior space.
Easy-access service panel: For machine roomless configurations with controller in the shaft, a service panel can be located inside or outside the shaft, making it accessible for maintenance.
Other standard features: Fully automatic operation, modular rail for easy construction, automatic cab on/off interior lighting, digital display in car operating panel, surface-mount telephone, oxford white ceiling with 4 LED pot lights, melamine interior in choice of colors or MDF panels.
Standard finishes: Flat melamine or unfinished MDF (see cab configurator), clear or bronze anodized aluminum cab operating panel and hall call stations, double plywood floor, oxford white ceiling.
Safety features: Battery operated (UPS) emergency lowering and lighting, hand-crank manual lowering, motorized braking, lockable control panel, elevator door interlocks, emergency stop switch, in-use indicator lights on hall stations, slack chain brake system.
Warranty: 36 months parts. Please see complete details here

Options

Optional configurations: Type 1, 2, 3, 4 and 5
Cab sizes:
W36'' x L48'' x H80'' (914 mm x 1219 mm x 2032 mm), Type 1, 2, 3, 4, 5
W36'' x L54'' x H80'' (914 mm x 1371 mm x 2032 mm), Type 1, 2, 3, 4, 5
W36'' x L60'' x H80'' (914 mm x 1524 mm x 2032 mm), Type 1, 2, 3, 4, 5
W40'' x L54'' x H80'' (1067mm x 1371 mm x2032 mm), Type 1, 2, 3, 4, 5
Custom cab sizes also available
Optional height: 84" (2133mm ), 96" (2438 mm)
Optional cab finishes: Hardwood, unfinished veneer, luxury MDF, routed white MDF (see cab configurator)
Optional fixture finishes: Brass #4 finish, stainless steel, blackened stainless steel or architectural white (handrail, cab operating panel, hall call stations). Hall call stations available in rectangular or oval design.
Optional touchscreen COP: large touchscreen to operate functions of elevator, customizable for landing names (at time of order), swipe to change animated screen themes. Not available for concurrent landing configurations.
Doors and gate options: Bi-folding doors, Panel-fold gate in clear anodized aluminum with clear acrylic inserts, or anodized bronze with bronze acrylic inserts, Visi-fold gate anodized bronze with bronze acrylic, Clear-fold gate in clear anodized aluminum with clear acrylic inserts. Power gate and door operators. For the ultimate in convenience, add Savaria automatic slim doors (requires minimum 84" cab height).
Other options: Up to 6 stops, machine roomless controller in hoistway, telephone cabinet,  alpha-numeric button marking, two-exit opening, speed upgrade to 50 fpm subject to local code, buffer springs, keyed hall call stations.

Specifications

Applications: Residential, indoors
Standard capacity: 750 lb (340 kg), 950 lb (431kg), 1000 lb (453 kg)
Maximum travel distance: 50' (15.24 m), 60' (18.29 m) where code permits with up to 6 stops and 2 openings
Nominal speed: 40 ft/min (0.20 m/s)
Motor: 2 hp with geared roller chain and variable frequency drive
Minimum pit: 8" (203 mm) recommended, but as shallow as 6" (152 mm) is possible; 10" (254 mm) required for HD model
Minimum overhead clearance: 96" (2438 mm)
Power supply: 230 volts, single phase, 60 Hz, 20 amps, 30 amp fused disconnect box with 20 amp fuse

Documents
    Videos

    Accessible version available here
